GEORGII KOBOLD GmbH & Co. KG Products
Overview of the Motors
Torque Motors KTY-Q
Torque Motors KTY-R
Torque Motors KTY-F
More Details:
High overloading capacity and extremely dynamic
High positioning accuracy because of the use of high-resolution encoder systems and the elimination of components that are susceptible to play and friction
Available with full shaft with/without keyway or with a hollow shaft on either the A and/or B side. Blind hole shafts, shafts with shrink disks or loose flanges are also possible.
Oscillation strength R is standard, but Class S (per DIN VDE 0530-14) is also possible
Flange dimensions are standardized to DIN 42 677, but special flanges are also available.
Flange accuracy in accordance with DIN 42 955
If desired, we can also increase the permissible radial and axial shaft loads
Fail-Safe brakes are also an option
KTY-Q Series of Torque Motors
The KTY-Q torque-motor series comes with three different flange sizes, and each flange size is available with 3-4 stack lengths. This broad range of motors neatly and efficiently covers your need for direct-drive torques from 14 to 270 Nm. The square design without a housing provides you with a very cost-effective direct-drive solution where IP54 is sufficient protection.
KTY-R Series of Torque Motors
For applications that demand IP65 protection, the KTY-R torque-motor series is the right choice. This series of direct-drive torque motors perfectly complements the KTY-Q series, because the KTY-R series is protected by a high-quality aluminum housing, which increases the protection class to IP65. This is the series to use to solve your applications which require a precise, direct-drive motor in difficult environmental conditions. Like the KTY-Q series, the KTY-R series motors are available in three diameters – each with 3-4 stack lengths to give meaningful coverage for torques ranging from 12 to 240 Nm.
